Tube: Black, oil and abrasion resistant HNBR for H2S sevice.
Reinforcement: Multiple plies of bias laid textile cord for extra strength and flexibility. Spirally wound, high tensile, multiple strand cables to provide unsurpassed ruggedness and reliability to withstand sudden high pressure.
Cover: Special flame resistant red Neoprene (CR) with optional stainless steel armor.
Temperature: -40 to 212° F.
Fittings: Integral connection flanged or hubbed.
Branding: NRP Choke & Kill Hose. MADE IN USA.
Part Number | Hose I.D (in) | Hose O.D. (in) | Rated W.P.(psi) | Test Pressure (psi) | Min. Bend Radius | Wt. Per Foot (lbs) |
5040-32 | 2.0 | 4.68 | 10000 | 15000 | 48 | 22.4 |
5040-40 | 2.50 | 5.34 | 10000 | 15000 | 52 | 27.4 |
5040-48 | 3.00 | 5.84 | 10000 | 15000 | 56 | 28.8 |
